Land Pride CGC1040

Land Pride CGC1040 for sale at Pillar Equipment, Quad Cities Region, Illinois

Double tap to zoom

Land Pride CGC1040 for sale at Pillar Equipment, Quad Cities Region, Illinois



Features

FEATURES BENEFITS
Attaches to compact utility loader quickly and easily Uses CII Quick-Attach design for quick and easy attachment.
Large jaw opening Allows the operator to grasp large or irregularly shaped objects.
40" working width Compact to complement the narrow width of compact utility loader.
Designed to protect hydraulic hoses Hydraulic hoses routed to prevent pinching.
Greasable hardened bushings at upper jaw pivot locations Provides years of service. Bushings can be replaced if needed.
1 1/4" Pivot pins Large diameter pins provide extra strength
Dual hydraulic cylinders Allows upper jaw to grip material firmly.
Greasable hardened bushings at cylinder mount locations Provides years of service. Bushings can be replaced if needed.
AR400 teeth material Provides high tensile strength and increased resistance to abrasion.

Specifications

Specifications CGC1040
Weight 307 lbs (139.3 kg)
Overall width 41 1/2" (105.4 cm)
Working width 40" (101.6 cm)
Closed height 29" (73.7 cm)
Jaw opening 32" (81.3 cm)
Hitch type CII Quick-Attach
Number of teeth 6 bottom & 5 top
Teeth spacing 8 1/8" (20.6 cm) upper & 7 7/8" (20 cm) lower
Tooth thickness 5/16" (8 mm)
Working length of teeth 8 3/8" (21.3 cm)
Hydraulic flow requirements 20 gpm (76 Lpm) max
Hydraulic couplers 1 male & 1 female
Hydraulic cylinders 1 1/2" x 8" x 1" rod
Maximum pressure rating 3000 psi (20.7 mPa)
